Item number: 0200333
2 Variants
piPREMIUM upgrade kit C33-200
Gives the possibility to bring the C33 conveyor series to the premium piFLOW®p platform.
Login or create account to access all our content and features!
Variants
0200333- 0200334
Features
- The kit is a plug-and–play assembly for a quick changeover to replace the Maxi L pump and top module
- COAX® patented technology
- Side mounted for low building height
- High vacuum flow
- Compact size and low weight
- Low noise level
- Modular design
- Pneumatic valve for compressed air to shock tank and mounting plate for the C series are included
General
Material
Al , ASTM 316L , Nitrile (NBR) , PA , PP , SS
Noise level
69 - 77 dBA
Temperature
0 - 60 °C
Weight, min.
10000 g
Performance
Feed pressure, max.
0.7 MPa
Feed pressure, optimum
0.4 - 0.6 MPa
Vacuum
60 - 75 -kPa
| Feed pressure | Air consumption | Vacuum flow (Nl/s) at different vacuum levels (-kPa) | Max vacuum | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MPa | Nl/s | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | -kPa |
| 0.5 | 12 | 46 | 26 | 17.6 | 11.2 | 6.8 | 5 | 2.8 | 1.4 | 0 | 0 | 70 |
| 0.4 | 10 | 40 | 23.2 | 15.2 | 9.6 | 6.4 | 3.2 | 0.8 | 0 | 0 | 0 | 60 |
| 0.6 | 14 | 48 | 28 | 20.8 | 13.6 | 7.2 | 4.8 | 4 | 2.8 | 0 | 0 | 75 |
